Smart storage solutions BEAM-IT-UP® which provides great functionality allowing belongings to be stored out of sight. BEAM-IT-UP® gives you more space! The ingenious ceiling storage system consisting of wall rails, beams and storage modules that elegantly clean up the space and due to the unique design, our BEAM-IT-UP® storage system fits into almost any room.
As an intermediate ceiling with function, the BEAM-IT-UP® storage system fits into almost any room:
It’s time for you to get a modern designed storage system to use unused space above your head. All you need is 2 parallel walls. You can choose different storage modules to go neatly under the ceiling, stable shelves or our stylish storage net give your room a unique design impression. The shoe storage or the practical storage organiser coming down from the ceiling to give you that extra storage space you need.
We are happy to advise you which sets can be combined, just give us a call.
THE ULTIMATE CEILING STORAGE SOLUTION
BEAM-IT-UP® can be configured according to your design with extra flexibility. Thanks to the different modules you can design the ceiling storage according to your lifestyle and design it your specification with our useful accessories. So, a small room in a shared apartment? Or a narrow corridor can be used as organised storage space. Enjoy more comfort and freedom at home with our BEAM-IT-UP® system
Whether for clothing, suitcases, sports accessories or toys - with BEAM-IT-UP® you can easily create extra space at home. Depending on the room size and wall conditions, different module combinations or sets are possible. The prerequisite are two opposite walls and it’s time to find your own space saving solution.
The most important preliminary considerations:
Now you’re ready you can start!
Have you decided where you want to install BEAM-IT-UP®?
First determine the wall type of the room or hallway (plasterboard, wood or concrete) and measure the width and height of the two opposite walls. Based on the width of the room
you can see which of the four different beams you need and how many modules you can place on them. Your room must be at least 94 cm and a maximum of 214 cm wide to use BEAM-IT-UP®. The ceiling height must be at least 240 cm or there must be 35 cm above the door frame.
HOW MUCH BEAM-IT-UP® CAN BE THERE?
The wall rails are 130 cm long. If the room is deeper, install several rails after each other. For smaller rooms, the rails can be cut very easily. Think carefully about how much length of your room you want to fill with BEAM-IT-UP®. Maybe two modules above the door will suffice in a 4-meter corridor - depending on how much storage space you want to create. The beams are fully adjustable and can be made up to 30 cm smaller at the ends. So, you are very flexible in planning your storage system.
Two modules side by side or one behind the other, three modules with gaps between them or only one module? So that you know exactly which and how many modules can be accommodated under your ceiling, you will need the exact dimensions of the room. You enter these directly in our online shop (link). So, you can determine the amount of wall rails and beams based on the room width and room length.
Room width of 125 cm x 260 cm room length ? space for max. 4 modules
Or 3 modules and an "empty space" to ensure an opening as access space
The construction beam stands so now you can fill it with the individual modules. If you need a handy shoe rack for 12 pairs of shoes? Then choose the shoe rack. Do you want to create storage space for skis, skateboards, suitcases or just your favorite music instrument? Then storage net and storage shelves are good choices. Or are you looking for real closet space BEAM-IT-UP® also has the solution for this. The storage box can be used for all types of items just like a closet just coming down from above. On our product page you will find the complete overview of all available modules.
Put the desired items in the shopping cart and complete the order process.
Optionally, you can supplement your BEAM-IT-UP with a flexible wardrobe with movable hooks. Or you order the wall hooks individually. A ladder in matching white for convenient access to the shelves is also available.
You can view our BEAM-IT-UP® brochure here and get a full overview of our unique ceiling storage system
See here how easy it is to install our BEAM-IT-UP® storage system - take a look here
Select width of your room in the drop down, there you will see the number of modules you can choose for your application.
You must measure the width in between two opposite walls.
Based on the width of the room, you can see which of the four different beams you are using and how many modules you can place on them. Your room must be at least 94 cm and a maximum of 214 cm wide to use BEAM-IT-UP®. If your room is wider than 214 cm the BEAM-IT-UP cannot be installed. To install BEAM-IT-UP® you must have minimum 35 cm above the door frame. That is the room BEAM-IT-UP® take in will with normal door mean that you need a ceiling height of at least 240 cm.
Yes, you can mount it yourselves. It is a real DIY project for handy men and women. Just view the installation video or follow the installation manual.
When mounting the wall rail, the wall material must be considered.
Is it stone, concrete, wood or lightweight walls?
For lightweight wall like dry wall, plaster walls or wood walls thinner than 30 mm you will need the raw plugs Fischer Duotec – therefore it is important to select your wall type – then you will receive the correct raw plugs with your order. The correct screws for the wall mounting (PH 6 x 60 mm torx) will also be included in the package.
For stone, (gas) concrete or wood thicker than 30 mm you need more basic raw plugs but we have prepared them for you in the package.
All you need is a drill, a spirit level and a screwdriver. The Fischer high quality plugs and screws you need for the installation are included in the construction base kit when you buy in on the DOLLE web shop.
Yes, we are happy to advise you by telephone which module and sets can be combined.
Contact us here TEL. 01245 362597
Yes, you can take your BEAM-IT-UP® with you when you move and when you take it down - then take your time and do it carefully to avoid scratches.
Is there such thing as a minimum measurement? The maximum width of your room to be able to use BEAM-IT-UP® is 214 cm wide. If your room is wider than 214 cm BEAM-IT-UP® cannot be installed. There is no maximum length ? the wall rail can install several rails after each other.
The storage box and the shoe box can carry 20 kg each, the storage net can carry 25 kg and the storage shelves can carry 40 kg. Only when you have a BEAM-IT-UP® system with the longest BEAM 214 on plaster walls the weight load is 30 kg on the storage shelf. The storage net and storage boxes are the same. The BEAM-IT-UP® storage system is validated by BIIR engineering and the max load per beam is 150 kg.
BIIR certification Max load 150 kg per BEAM evenly distributed. (3x 50 kg)
No, the BEAM-IT-UP® is not tested as a high bed, so we cannot recommend it for sleeping.
Yes, BEAM-IT-UP® is modular and can be extended endless.
The shoe storage and storage box organizer are coming down from above to give you storage in a comfortable height when you are more than 160 cm high. People and children below 160 cm cannot work the system without a stool or a small ladder. *Being 160 cm, you need to mount the BEAM-IT-UP® in a height of 210 cm to have a normal operation of the BEAM-IT-UP® without a stool.
The BEAM-IT-UP® is designed by Scandinavians designers C.F. Møllers and that is shown in the clean and simple lines. The storage modules are white, and the beautiful beams and rails are in aluminium, so a very nice combination of white and aluminium.
Yes the BEAM-IT-UP® has normal warranty of 2 years.
We are very proud to present our designers. Together with DOLLE's Research and Development department CF Møller Design has designed and invented this outstanding innovative storage system BEAM-IT-UP®.
The BEAM-IT-UP® is designed by C.F. Møller Design to optimize space in smaller places. More people are moving to urban areas and this is a great reason to start thinking in cubic meters and getting the most out of one's available living space. It requires creative thinking when larger items winter clothing and shoes need to be stored away. C.F. Møller took this challenge up together with DOLLE and created this BEAM-IT-UP® to make better use of living space.
C.F. Møller Design is an integral part of C.F. Møller Architects, one of Scandinavia's leading architectural firms. C.F. Møller Design cooperates with Danish and international companies on the design and development of innovative and meaningful products for houses, their surroundings and life within them. C.F. Møller Design builds on Scandinavian design traditions and is guided by a simple and distinct expression with focus on function, aesthetics and communication. We approach every assignment with an open mind and focus on creating useful and original designs with enduring qualities. C.F. Møller Design is responsible for a wide range of interiors, furnishings, building components and products.
Smoke detectors installed above the BEAM-IT-UP® system should be installed in a manner that does not impact its function or effectiveness. This could be achieved by leaving the area below the smoke detector open. If this is not feasible, the smoke detector should be relocated to a location outside of the BIU system. Please follow the mounting instruction on your smoke alarm.
No fire exits should be blocked after the BEMA-IT-UP® system is installed. Please follow any direction on fire exits and the surrounding area.
Sometimes installation of BEAM -IT-UP® can include the establishment of new lighting. i.e wall lights.
Here we have some examples of how to solve lighting.
Below there is lighting in the ceiling that gives a good overall illumination. In addition, there are some less powerful wall lights plus a table lamp to provide ambient lighting. Also, the space at the sides let light through.
In general, there is often room for adequate lightning in the ceiling ? like here where the lamp is mounted in the loft and not hanging down.
Here in the middle of the hallway we have sufficient lighting in the ceiling. In addition, there are wall lights and mirror lighting that have been added giving atmosphere. Only the imagination will stop you.
In this BEAM-IT-UP® ladder installation light can come down through the access opening.
Lamps hanging down through the open structure at the sides is also an option.
From the simple storage shelf to the storage box, you can combine different modules with BEAM-IT-UP®. Side by side or one behind the other - depending on how your room is designed and what you want to store in the BEAM-IT-UP®.
The special feature of the storage box and shoe rack is the possibility of conveniently folding it up and down. You do not have to climb a ladder but bring the storage space down just like a closet and with the gas springs in the ceiling storage box ensure easy opening and closing. The lightweight storage box with 3 compartments when closed protects against dust and dirt. The shoe rack scores with a visually lightweight and sturdy frame on which shoes of all sizes can be well distributed.
The wall rails are 130 cm long and can be mounted or shortened one behind the other. The beams are available in 4 different widths and can be extended telescopically by another 30 cm, so they fit in spaces from 94 to 214 cm wide. The storage modules are placed exclusively on the fixed, non-extendable, areas of the beams!
When mounting the wall rail and selecting the modules, the wall material must be considered. Is it stone, concrete, wood or lightweight walls?
In addition to BEAM-IT-UP® smart storage, we have a ladder and a flexible wall hook system - we call it hook-it-up to complement BEAM-IT-UP®. Perfect finish to the room just place your desired accessories in the cart.
